DIN EN X9CrMnNiCu17-8-5-2 1.4618 Stainless Steel Flat Bar X9CrMnNiCu17-8-5-2 Flat Bar 1.4618
Description
Our company provides DIN EN X9CrMnNiCu17-8-5-2 1.4618 Stainless Steel annealed Flat Bar X9CrMnNiCu17-8-5-2 Q+T Flat Bar 1.4618 Quenched and tempered Bar.
All of DIN EN X9CrMnNiCu17-8-5-2 1.4618 Stainless Steel annealed Flat Bar X9CrMnNiCu17-8-5-2 Q+T Flat Bar 1.4618 Quenched and tempered Bar conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
- Material:Metal,Stainless Steel Flat Bar,DIN EN X9CrMnNiCu17-8-5-2 1.4618.
- Shape:Stainless Steel Flat Bar.
- Length: Fixed length or random length or based on the customer's special requirement.
- Square bar / Flat bar: 3mm to 800mm
-
Surface:Black,Bright,Rrough Turned,Grinding,Centreless Ground
Products Details
DIN EN X9CrMnNiCu17-8-5-2 1.4618 Stainless Steel annealed Flat Bar X9CrMnNiCu17-8-5-2 Q+T Flat Bar 1.4618 Quenched and tempered Bar
| Chemical Composition (weight%): | C (％): ≤ 0.10 |
| Si (％): ≤ 1.00 |
| Mn(％): 5.50 ~ 9.50 |
| P(％): ≤ 0.035 |
| S (％): ≤0.010 |
| Cr (％): 16.5 ~ 18.5 |
| Mo (％): - |
| Ni (％): 4.50 ~ 5.50 |
| Cu (%): 1.00 ~ 2.50 |
| N (％): ≤ 0.15 |
Mechanical Properties Under
Final Heat Treatment: | Form: Cold rolled strip |
| Tensile strength, TS, σb/≥ MPa: 430 ~ 630 |
| Yield strength, YS, σ0.2/≥ MPa: 280 |
| Elongation, EL, δ ≥(％): 22.0 |
| Reduction of area, RA, (%): - |
| Annealed hardness, HB ≤: - |
| Heat treatment pratice: Solution annealed 1000 ~ 1100 ℃, air or water cooled. |
Applications:
DIN EN X9CrMnNiCu17-8-5-2 1.4618 Stainless Steel annealed Flat Bar X9CrMnNiCu17-8-5-2 Q+T Flat Bar 1.4618 Quenched and tempered Bar
Bolt and nut,Chemical equipment,Mechanical parts used in the condition of corrosion resistance,Pressure vessel.
Equivalent Grade
DIN EN X9CrMnNiCu17-8-5-2 DIN EN 10088-1 2014
1.4618
DIN EN X9CrMnNiCu17-8-5-2 1.4618 Stainless Steel annealed Flat Bar X9CrMnNiCu17-8-5-2 Q+T Flat Bar 1.4618 Quenched and tempered Bar
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of DIN EN X9CrMnNiCu17-8-5-2 1.4618 Stainless Steel annealed Flat Bar X9CrMnNiCu17-8-5-2 Q+T Flat Bar 1.4618 Quenched and tempered Bar and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging, we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
