W-Nr 1.4913 Stainless Steel Flat Bar W-Nr 1.4913 Flat Bar W-Nr 1.4913 Bar
Description
Our company provides W-Nr 1.4913 Black / Bright Stainless Steel Flat Bar W-Nr 1.4913 Rrough Turned / Grinding Round Bar W-Nr 1.4913 Forged / Hot Rolled Flat Bar.
All of W-Nr 1.4913 Black / Bright Stainless Steel Flat Bar W-Nr 1.4913 Rrough Turned / Grinding Round Bar W-Nr 1.4913 Forged / Hot Rolled Flat Bar. conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
- Material:Metal,Stainless Steel Flat Bar,W-Nr 1.4913.
- Shape:Stainless Steel Flat Bar.
- W-Nr 1.4913 Round bar / Wire rod (Diameter): 5.5mm to 800mm;Square bar / Flat bar: 3mm to 800mm
Products Details
W-Nr 1.4913 Black / Bright Stainless Steel Flat Bar W-Nr 1.4913 Rrough Turned / Grinding Round Bar W-Nr 1.4913 Forged / Hot Rolled Flat Bar.
| Chemical Composition (weight%): | C (％): 0.17 ~ 0.23 |
| Si (％): ≤ 0.50 |
| Mn (％): 0.40 ~ 0.90 |
| P (％)≤: 0.025 |
| S (％)≤: 0.015 |
| Cr (％): 10.0 ~ 11.5 |
| Ni (％): 0.20 ~ 0.60 |
| Mo (％): 0.50 ~ 0.80 |
| Al (%): ≤ 0.020 |
| V (%): 0.10 ~ 0.30 |
| W (%): - |
| Nb (%): 0.25 ~ 0.55 |
| N (％): 0.05 ~ 0.10 |
| B (%): ≤ 0.0015 |
Mechanical Properties Under
Final Heat Treatment:
| Condition: heat treatment |
| Tensile strength, σb/MPa: 950 ~ 1150 |
| Yield strength, σs≥/MPa: 780 min. |
| Elongation, δ5≥(％): 10.0 |
| Non-scale temperature in Air: -℃ |
Applications:
W-Nr 1.4913 Black / Bright Stainless Steel Flat Bar W-Nr 1.4913 Rrough Turned / Grinding Round Bar W-Nr 1.4913 Forged / Hot Rolled Flat Bar.
Gas turbine,Turbine blade,Heat treating fixture,Furnace muffle,Nuclear reactor,Turbine engine parts - mechanical gears, gear shaft, main axis, blade,Mechanical parts - bolt and nut, fastener,Heat treatment furnace flask and components, especially in the carbonization.
These materials must stand up to high heat, extreme oxidation potential and recycling.
Equivalent Grade:
X19CrMoNbVN11-1
W-Nr 1.4913
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of W-Nr 1.4913 Black / Bright Stainless Steel Flat Bar W-Nr 1.4913 Rrough Turned / Grinding Round Bar W-Nr 1.4913 Forged / Hot Rolled Flat Bar and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging, we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
Submit an enquiry for the displaying steel materials you are interested in TODAY!
