ASTM XM-13 Stainless Steel Flat Bar UNS S13800
Description
All of ASTM XM-13 Stainless Steel Flat Bar conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
- Material:Metal,Stainless Steel Flat Bar,PH13-8Mo, ASTM XM-13, UNS S13800
- Shape:Stainless Steel Flat Bar.
- Square bar / Flat bar: 3mm to 800mm.
Products Details
| Chemical Composition (weight%): | C(％): ≤ 0.05 |
| Si (％): ≤ 1.00 |
| Mn (％): ≤ 0.20 |
| P(％):≤ 0.010 |
| S (％):≤ 0.008 |
| Cr (％): 12.3 ~ 13.2 |
| Ni (％): 7.50 ~ 8.50 |
| Mo (％): 2.00 ~ 2.50 |
| N (％): ≤ 0.01 |
| Al (％): 0.90 ~ 1.35 |
Mechanical Properties Under
Final Heat Treatment: | Solution treatment temperature and cooling ways: 927 +/-15℃ |
| Steel plate thickness /mm: 0.038~101.6 |
| Tensile strength, σb≥/MPa: - |
| Yield strength, σ0.2≥/MPa: - |
| Elongation, δ ≥(％): - |
| Hardness ≤|HRC: 38 |
| Hardness ≤|HBS: 363 |
Applications:
ASTM XM-13 Stainless Steel Flat Bar is a martensitic precipitation-hardening stainless steel that has excellent strength, high hardness, superior toughness, and good corrosion resistance.
Compared to other ferrous-base materials ASTM XM-13 Stainless Steel offers a high level of useful mechanical properties under severe environmental conditions.
ASTM XM-13 Stainless Steel uses: Aerospace components, landing gear, nuclear reactor components, petrochemical industry, injection molding equipment etc.
Equivalent Grade
PH13-8Mo, ASTM XM-13, UNS S13800
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of ASTM XM-13 Stainless Steel Flat Bar UNS S13800 and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging, we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
