AISI 422 Stainless Steel Flat Bar UNS S42200 Diameter 5.5mm To 800mm

Name: AISI 422 Stainless Steel Flat Bar UNS S42200 Diameter 55mm To 800mm
Brand: PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Price: 1 USD

China AISI 422 Stainless Steel Flat Bar UNS S42200 Diameter 5.5mm To 800mm wholesale

Brand Name : PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL

Model Number : ASTM Grade 422, AISI 422, UNS S42200

Certification : SGS,TUV,BV,ISO,MTC

Place of Origin : China

MOQ : Negotiations

Price : Negotiations

Payment Terms : T/T

Supply Ability : 110000KGS/Month

Delivery Time : Ex-stock for delivery: 3-7 days Production lead time: 50-60days

Packaging Details : Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement

Product Name : ASTM Grade 422 Stainless Steel Flat Bar

Grades : ASTM Grade 422, AISI 422, UNS S42200

Processing methods : Ground,Peeled,Cold working,Machined,etc

Surface : Rrough Turned,Grinding,Centreless Ground,etc

Profile : Round Bar,Sheets Plates,Forging Piece,etc

Price Term : Ex-work,FOB,CIF,CFR, DDU,etc

Contact Now

ASTM Grade 422 Stainless Steel Flat Bar AISI 422 UNS S42200

Description

ASTM Grade 422 Stainless Steel Flat Bar AISI 422 UNS S42200 is a hardenable, martensitic stainless steel with exceptional creep rupture properties between 600-1200°F. Depending on the form, section, and application involved, this stainless steel can be heat-treated to different high strength levels. ASTM Grade 422 Stainless Steel Flat Bar AISI 422 UNS S42200 acquires high mechanical properties through heat treatment and possesses good oxidation and scaling resistance properties.
All of ASTM Grade 422 Stainless Steel Flat Bar AISI 422 UNS S42200 conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.

Material:Metal, ASTM Grade 422 Stainless Steel Flat Bar AISI 422 UNS S42200
Shape: Stainless Steel Round Bar
Round bar / Wire rod (Diameter): 5.5mm to 800mm
Heavy/middle plate via hot rolled: T6 - 200mm X W10 - 1500mm X L1000-12000mm
Sheet steel via cold rolled: T0.5 - 6mm X W6 - 1000mm X L1000 - 2000mm
Steel strip via cold rolled: T0.1 - 3mm X W5 - 200mm X L (or in coil form)
Length: Fixed length or random length or based on the customer's special requirement.

Products Details

ASTM Grade 422 Stainless Steel Flat Bar AISI 422 UNS S42200

Chemical Composition (weight%):

C (％): 0.20 ~ 0.25
Si (％): ≤ 0.50
Mn (％): 0.50 ~ 1.00
P (％)≤: 0.030
S (％)≤: 0.025
Cr (％): 11.0 ~ 13.5
Ni (％): 0.50 ~ 1.00
Mo (％): 0.90 ~ 1.25
W (％): 0.90 ~ 1.25
V (%): 0.20 ~ 0.30
Cu (%): ≤ 0.50

Mechanical Properties Under Final Heat Treatment:

Conditon of delivery: annealed
Tensile strength, σb ≥/MPa: -
Yield strength, σ0.2 ≥/MPa:-
Elongation, δ ≥(％): -
Reduction of area, ф ≥(％): -
Hardness | HRS: ≤ 248
Condition of delivery: + T
Tensile strength, σb ≥/MPa: -
Yield strength, σ0.2 ≥/MPa:-
Elongation, δ ≥(％): -
Reduction of area, ф ≥(％): -
Hardness | HRS: ≤285
Condition of heat treatment: HT 1022℃ ~ 1050℃ air or oil cooled, ≥620℃ X 2H, tempered
Tensile strength,σb ≥/MPa: 965
Yield strength, σ0.2 ≥/MPa: 760
Elongation,δ ≥(％): 13.0
Reduction of area, ф ≥(％): 30.0
Hardness | HRS: 302 ~ 352
Condition of heat treatment: H 1022℃ ~ 1050℃ air or oil cooled, ≥677℃ X 2H, tempered
Tensile strength,σb ≥/MPa: 825
Yield strength, σ0.2 ≥/MPa: 585
Elongation,δ ≥(％): 15.0
Reduction of area, ф ≥(％): 35
Hardness | HRS: 241 ~ 285

AISI 422 Stainless Steel Flat Bar UNS S42200 Diameter 5.5mm To 800mm

Applications:

ASTM Grade 422 Stainless Steel Flat Bar AISI 422 UNS S42200 used most often in the Aircraft parts, Steam and gas turbine components, Compressor and turbine wheels, High heat components, Thermal engines components.

Equivalent Grade

ASTM Grade 422 AISI 422 UNS S42200

AISI 422 Stainless Steel Flat Bar UNS S42200 Diameter 5.5mm To 800mm
ASTM Grade 422 Stainless Steel Flat Bar AISI 422 UNS S42200

FAQ

Q: How do you control the quality?

A: We have professional inspectors to analyze the chemical composition of ASTM Grade 422 Stainless Steel Flat Bar AISI 422 UNS S42200 and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.

Q: Do you accept customization?

A: Yes. If you have special requirements for products or packaging, we can make them for you.

Q: Can you accept trial orders?

A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.

Q: How do I get samples?

A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.

AISI 422 Stainless Steel Flat Bar UNS S42200 Diameter 5.5mm To 800mm
Packing method

Wooden Pallet BOX,Standard Seaworthy Package,based on the customer's special requirement,etc
