17-4 PH Alloy Round Bar AISI 630 UNS S17400

Name: 174 PH Alloy Round Bar AISI 630 UNS S17400
Brand: PANGANGGROUP,ANSTEEL,TISCO,BAOSTEEL
Price: 1 USD

China 17-4 PH Alloy Round Bar AISI 630 UNS S17400 wholesale

Brand Name : PANGANGGROUP,ANSTEEL,TISCO,BAOSTEEL

Model Number : 17-4 PH, AISI 630, UNS S17400

Certification : SGS,TUV,BV,ISO,MTC

Place of Origin : China

MOQ : Negotiations

Price : Negotiations

Payment Terms : T/T

Supply Ability : 45000KGS/Month

Delivery Time : Ex-stock for delivery: 3-7 days Production lead time: 30-60 days

Packaging Details : Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement

Product name : 17-4 PH Alloy Round Bar

Grades : 17-4 PH, AISI 630, UNS S17400

Processing methods : Milled, Cold working,etc.

Heat treatment condition : Quenched And Tempered,etc

Surface : Grinding, Centreless Ground, etc

Available Shapes : Round bar, Heavy, Sheet steel via cold rolled, Steel strip via cold rolled, Forging piece,etc

Price Term : Ex-work, FOB, CIF, CFR, DDU etc.

Contact Now

17-4 PH Alloy Round Bar AISI 630 UNS S17400

Description

17-4 PH Alloy Round Bar is a precipitation hardening martensitic stainless steel. Strength and toughness desired can be manipulated by temperate range in the heat treatment process.

All of 17-4 PH Alloy Round Bar AISI 630 UNS S17400 conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.

Material:Metal, Alloy Round Bar, 17-4 PH
Shape:Alloy Round Bar
Round bar / Wire rod (Diameter): 5.5mm to 800mm
Heavy/middle plate via hot rolled: T6 - 200mm X W10 - 1500mm X L1000-12000mm
Sheet steel via cold rolled: T0.5 - 6mm X W6 - 1000mm X L1000 - 2000mm
Steel strip via cold rolled: T0.1 - 3mm X W5 - 200mm X L (or in coil form)
Length: Fixed length or random length or based on the customer's special requirement.

Products Details

17-4 PH Alloy Round Bar AISI 630 UNS S17400

Chemical Composition (weight%):	Mechanical Properties Under Final Heat Treatment:
C(％): ≤0.07 Si(％): ≤1.00 Mn(％): ≤1.00 P(％)≤: 0.040 S(％)≤: 0.030 Cr(％): 15.5～17.5 Ni(％): 3.00～5.00 Mo(％): — Other(％): Cu 3.00～5.00,Nb 0.15～0.45	Properties: Metric Shear modulus: 77.4 GPa Elastic modulus: 190-210 GPa Poisson's ratio: 0.27-0.30 Hardness, Brinell: 352

17-4 PH Alloy Round Bar AISI 630 UNS S17400

Applications:

17-4 PH Alloy Round Bar AISI 630 UNS S17400 is often used in the industries including pump shafts, oil path, mechanical seals, and within the aerospace industry etc.

17-4 PH Alloy Round Bar AISI 630 UNS S17400

FAQ

Q: How do you control the quality?

A: We have professional inspectors to analyze the chemical composition of raw materials and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.

Q: Do you accept customization?

A: Yes. If you have special requirements for products or packaging, we can make them for you.

Q: Can you accept trial orders?

A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.

Q: How do I get samples?

A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.

17-4 PH Alloy Round Bar AISI 630 UNS S17400
