AMS 5610 Stainless Steel Flat Bar UNS S41623 UNS S41600 Flat Bar

Name: AMS 5610 Stainless Steel Flat Bar UNS S41623 UNS S41600 Flat Bar
Brand: PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Price: 1 USD

China AMS 5610 Stainless Steel Flat Bar UNS S41623 UNS S41600 Flat Bar wholesale

Brand Name : PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL

Model Number : AMS 5610, UNS S41623, UNS S41600

Certification : SGS, TUV, BV, ISO, MTC

Place of Origin : China

MOQ : 1000kg

Price : Negotiations

Payment Terms : T/T

Supply Ability : 45000KGS/Month

Delivery Time : Ex-stock for delivery: 3-7 days Production lead time: 30-60 days

Packaging Details : Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement

Characteristic : Corrosion and Heat-Resistant

Heat treatment condition : +N, +NT, +QT, etc.

Processing methods : Hot Working, Machined. etc

Available Shapes : Bars, Wire, Tubing, Forgings...

Surface : peeled + polishing, etc.

Application : Turbine rotors, Vanes, Dowels, Flanges, Fittings

Material Category : Martensitic stainless steel

Contact Now

AMS 5610 Stainless Steel Flat Bar UNS S41623 UNS S41600 Flat Bar
Describe

AMS 5610 stainless steel is a martensitic stainless steel formulated for primary forming into wrought products. Cited properties are appropriate for the annealed condition.It has a moderately low embodied energy among wrought martensitic stainless steels. In addition, it has a moderately high ductility and a fairly low tensile strength.

Size Range

Round bar / Wire rod (Diameter):	4.0mm to 800mm
Square bar / Flat bar:	3.0mm to 1000mm
Forging piece:	Stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled:	T6 - 250mm X W10 - 1500mm X L1000-11000mm
Sheet steel via cold rolled:	T0.5 - 4mm X W6 - 1000mm X L1000 - 1000mm
Steel strip via cold rolled:	T0.1 - 3.0mm X W5 - 190mm X L (or in coil form)
Length	Fixed length or random length or based on the customer's special requirement.

Chemical Composition and standard

Grade	AMS 5610
standard	SAE AMS 5610N-2012
Chemical Composition (weight%)	C(％): ≤0.15 Se(％): 0.18~0.35 Si(％): ≤1.0 Cu(％): ≤0.50 Mn(％): ≤1.25 P(％)≤: 0.06 S(％)≤: 0.03 Cr(％): 11.5~13.5 Ni(％): ≤0.75 Mo / Zi(％): ≤0.60

AMS 5610 Stainless Steel Flat Bar UNS S41623 UNS S41600 Flat Bar

Mechanical Properties

AMS 5610 Stainless Steel Mechanical Properties

Tensile strength,Rm/MPa:	≥485
Yield strength,Rp/MPa:	≥275
Elongation/%:	≥20
Reduction of area, ψ/%:	≥45
Impact, KV /J:	--
Annealed hardness HB:	≤223
