AMS 6547 Turbine Blade Steel UNS K43214 Wire Rod

Name: AMS 6547 Turbine Blade Steel UNS K43214 Wire Rod
Brand: PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Price: 1 USD

China AMS 6547 Turbine Blade Steel UNS K43214 Wire Rod wholesale

Brand Name : PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL

Model Number : AMS 6547, UNS K43214

Certification : SGS, TUV, BV, ISO, MTC

Place of Origin : China

MOQ : 1000kg

Price : Negotiations

Payment Terms : T/T

Supply Ability : 50000KGS/Month

Delivery Time : Ex-stock for delivery: 3-7 days Production lead time: 30-60 days

Packaging Details : Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement

Characteristic : Corrosion and Heat-Resistant

Heat treatment condition : +AT, +P, etc.

Processing methods : Milled, Cold working, etc

Available Shapes : Bars, Forgings, Tubing...

Surface : peeled + polishing, etc.

Application : Forged Fittings, Valves, Components

Material Category : --

Contact Now

AMS 6547 Turbine Blade Steel UNS K43214 Wire Rod

Size Range

Round bar / Wire rod (Diameter):	5.0mm to 100mm
Square bar / Flat bar:	5.0mm to 500mm
Forging piece:	Stepped shafts with flanks/discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled:	T5 - 500mm X W10 - 1500mm X L1000-11000mm
Sheet steel via cold rolled:	T0.3 - 5mm X W5 - 1000mm X L1000 - 1000mm
Steel strip via cold rolled:	T0.3 - 5.0mm X W5 - 180mm X L (or in coil form)
Length	Fixed length or random length or based on the customer's special requirement.

Chemical Composition and standard

Grade

AMS 6547

standard

SAE AMS 5647-2013

Chemical Composition (weight%)

C(％): 0.12~0.17
Si(％): 0.15~0.40
Mn(％): 0.30~0.60
P(％)≤: 0.025
S(％)≤: 0.015
Cr(％): 0.80~1.10
Ni(％): 3.0~3.50
Mo(％): 0.22~0.32
Cu(％): ≤ 0.35

AMS 6547 Turbine Blade Steel UNS K43214 Wire Rod

Mechanical Properties

AMS 5627 Turbine Steel Mechanical Properties

Tensile strength, Rm/MPa:	1180~1380
Yield strength, Rp/MPa:	≥980
Elongation/%:	--
Reduction of area, ψ/%:	--
Impact, KV /J:	--
Annealed hardness HB:	≤285
