X20CrMo13 W-Nr 1.4120 Stainless Steel Round Bar G-X20CrMo13 Hot Rolled Strips

Name: X20CrMo13 WNr 14120 Stainless Steel Round Bar GX20CrMo13 Hot Rolled Strips
Brand: PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Price: 1 USD

China X20CrMo13 W-Nr 1.4120 Stainless Steel Round Bar G-X20CrMo13 Hot Rolled Strips wholesale

Brand Name : PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL

Model Number : DIN X20CrMo, W-Nr 1.4120, G-X20CrMo13

Certification : SGS, TUV, BV, ISO, MTC

Place of Origin : China

MOQ : 500kg

Price : Negotiations

Payment Terms : T/T

Supply Ability : 50000KGS/Month

Delivery Time : Ex-stock for delivery: 3-7 days Production lead time: 30-60 days

Packaging Details : Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement

Characteristic : Corrosion Resistant

Heat treatment condition : +AT, +P, etc

Processing methods : Cold working, Hot Working, etc

Available Shapes : Forging piece, Tubing, Steel plate, etc

Surface : Peeled, Rrough Turned, etc

Material Category : Martensitic Stainless Steel

Contact Now

X20CrMo13 W-Nr 1.4120 Stainless Steel Round Bar G-X20CrMo13 Hot Rolled Strips

Size Range

Round bar / Wire rod (Diameter):

5.5 mm to 1000 mm

Square bar / Flat bar:

3.5 mm to 500 mm

Forging piece:

Stepped shafts with flanks/discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.

Heavy/middle plate via hot rolled:

T5.0 - 100 mm X W7 - 1000 mm X L1000-10000 mm

Sheet steel via cold rolled:

T0.5 - 10.0 mm X W5 - 1000 mm X L1000 - 10000 mm

Steel strip via cold rolled:

T0.3 - 10.0 mm X W5 - 1000 mm X L (or in coil form)

Length:

Fixed length or random length or based on the customer's special requirement.

Chemical Composition and standard

G-X20CrMo13/X20CrMo/1.4120

DIN 17442-1977/SEW 400(1997)

C(％): 0.17~0.22
Si(％): ≤1.00
Mn(％): ≤1.00
P(％)≤: 0.040
S(％)≤: 0.015
Cr(％): 12.0~14.0
Ni(％): ≤1.00
Mo(％): 0.9~1.3

X20CrMo13 W-Nr 1.4120 Stainless Steel Round Bar G-X20CrMo13 Hot Rolled Strips

Mechanical Properties

X20CrMo/1.4120 Tool Steel Mechanical Properties

Property	Tempering	Value
After annealing hardness ≤ HBS	--	260
Hardening value after tempering/MPa	400℃	--
	500℃	1470
	600℃	1180
	650℃	980

Application

X20CrMo/1.4120 tool steel is widely used in medical, aerospace, transportation industries
