1.4828 DIN X15CrNiSi20-12 Stainless Steel Round Bar Alloy 309 UNS S30900 Plates

Name: 14828 DIN X15CrNiSi2012 Stainless Steel Round Bar Alloy 309 UNS S30900 Plates
Brand: PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Price: 1 USD

China 1.4828 DIN X15CrNiSi20-12 Stainless Steel Round Bar Alloy 309 UNS S30900 Plates wholesale

Brand Name : PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL

Model Number : 1.7703, 13CrMoV9-10

Certification : SGS, TUV, BV, ISO, MTC

Place of Origin : China

MOQ : 800kg

Price : Negotiations

Payment Terms : T/T

Supply Ability : 50000KGS/Month

Delivery Time : Ex-stock for delivery: 3-7 days Production lead time: 30-60 days

Packaging Details : Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement

Product Name : 1.4828 DIN X15CrNiSi20-12 309 Stainless Steel

Characteristic : ire Rod, Sheet Steel, Plate

Heat treatment condition : +QT, +AT, etc

Processing methods : Milled, Cold working, etc

Available Shapes : Forging piece, Tubing, etc

Surface : Peeled, Polished, etc

Contact Now

1.4828 DIN X15CrNiSi20-12 Stainless Steel Round Bar Alloy 309 UNS S30900 Plates

Product Information

X15CrNiSi20-12/1.4828 steel is produced into coils, bars and tubes in the form of hot-rolled plates to produce special load parts and subclasses that can withstand long-term high temperature.

Size Range

Round bar / Wire rod (Diameter): 5.0 mm to 500 mm

Square bar / Flat bar: 5.0 mm to 500 mm

Forging piece: Stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.

Heavy/middle plate via hot rolled: T5 - 1000 mm X W10 - 1000 mm X L800-12000 mm

Sheet steel via cold rolled: T5.0 - 10 mm X W10 - 1000 mm X L100 - 1000 mm

Steel strip via cold rolled: T7 - 10 mm X W10 - 1000 mm X L (or in coil form)

Length: Fixed length or random length or based on the customer's special requirement.

Chemical Composition and standard

X15CrNiSi20-12

1.4828

AISI 309

UNS S30900

BS 309S24

JIS SUH309

EN 10296-2-2005

ASTM A 959-2004

BS 1449-2-1983

JIS G 4312-2019

C(％): ≤0.2
Si(％): 1.5~2.5
Mn(％): ≤2.0
P(％)≤: 0.045
S(％)≤: 0.015
Cr(％): 19.0~21.0
Ni(％): 11.0~13.0

Mo(%): -

N(%): ≤0.11

C(％): ≤0.2
Si(％): ≤1.0
Mn(％): ≤2.0
P(％)≤: 0.045
S(％)≤: 0.03
Cr(％): 22.0~24.0
Ni(％): 12.0~15.0

Mo(%): -

N(%): -

C(％): ≤0.15
Si(％): ≤1.0
Mn(％): ≤2.0
P(％)≤: 0.045
S(％)≤: 0.03
Cr(％): 22.0~25.0
Ni(％): 13.0~16.0

Mo(%): -

N(%): -

C(％): ≤0.2
Si(％): ≤1.0
Mn(％): ≤2.0
P(％)≤: 0.045
S(％)≤: 0.03
Cr(％): 22.0~24.0
Ni(％): 12.0~15.0

Mo(%): -

N(%): -

1.4828 DIN X15CrNiSi20-12 Stainless Steel Round Bar Alloy 309 UNS S30900 Plates

X15CrNiSi20-12/1.4828 Mechanical Properties (+P)

Tensile Strength, σb/MPa: ≥550

Yield Strength, σ0.2/MPa: ≥230

Elongation, δ(％): ≥30

Applications

X15CRNISI20-12 W-NR 1.4828 is used to produce special furnace and conveyor components operating at high temperature, such as hooks, porcelain baskets, chimneys and special items operating in dry environment.
