X22CrNiMoV12-1 Turbine Blade Steel 1.4923 1.4934 Round Bar X22CrMoV12-1 TLV 9248 06 Flat Bar
Description
Our company provides X22CrNiMoV12-1 Turbine Blade Steel X22 Round Bar 1.4923 1.4934 Flat Bar X22CrMoV12-1 TLV 9248 06 Bar.
All of X22CrNiMoV12-1 Turbine Blade Steel X22 Round Bar 1.4923 1.4934 Flat Bar X22CrMoV12-1 TLV 9248 06 Bar conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
- Material:Metal,Turbine Blade Steel,X22CrNiMoV12-,XM-22,DIN 1.4923 1.4934,X22CrMoV12-1,TLV 9248 06.
- Shape:Turbine Blade Steel.
- Round bar / Wire rod (Diameter): 5.5mm to 800mm
- Square bar / Flat bar: 3mm to 800mm
Products Details
X22CrNiMoV12-1 Turbine Blade Steel X22 Round Bar 1.4923 1.4934 Flat Bar X22CrMoV12-1 TLV 9248 06 Bar
| Chemical Composition (weight%): | Mechanical Properties Under Final Heat Treatment: |
C (％): 0.18 ~ 0.24
Si (％): 0.18 ~ 0.24
Mn (％): 0.40 ~ 0.90
P (％)≤: 0.025
S (％)≤: 0.015
Cr (％): 11.0 ~ 12.5
Ni (％): 0.30 ~ 0.80
Mo (％): 0.80 ~ 1.20
V (％): 0.25 ~ 0.35 | Hot forming temperature /℃: 1100～850
Heat treatment temperature /℃ | annealing: 750~780
Heat treatment temperature /℃ | quenching or solution: 1035 ~ 1065 air / oil
Heat treatment temperature /℃ | tempering: 700~750
Heat treatment temperature /℃ | ageing: 630~750-
Condition: heat treatment
Mechanical property under room temperature |σb/MPa: 800~ 950
Mechanical property under room temperature |σs≥/MPa: 600
Mechanical property under room temperature |δ5≥(％): 14
Mechanical property under room temperature |Akv(DVM): 34
Heat stability temperature/℃: 580
Non-scale temperature in air /℃: 600 |
Applications:
X22CrNiMoV12-1 Turbine Blade Steel X22 Round Bar 1.4923 1.4934 Flat Bar X22CrMoV12-1 TLV 9248 06 Bar
Chemical equipment
Mechanical parts used in the condition of corrosion resistance
Bolt and nut
Pressure vessel
Heat-resistant steel is widely used in the field of manufacturing the boiler, steam turbine, motive power machine, industrial furnace, and other mechanical parts of aviation, petrochemical engineering operating at high temperature. Those parts must hold the features: high temperature strength, resistance to high temperature oxide etch, enough toughness, excellent machinability, weldability, structure stability based on different usages.
Equivalent Grade:
X22CrNiMoV12-1
XM-22
DIN 1.4923
1.4934
X22CrMoV12-1
TLV 9248 06
X22CrNiMoV12-1 Turbine Blade Steel X22 Round Bar 1.4923 1.4934 Flat Bar X22CrMoV12-1 TLV 9248 06 Bar
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of raw materials and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging, we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
Product Tags:
|
|
X22CrNiMoV12-1 1.4923 1.4934 Round Steel Rod TLV 9248 06 Flat Bar Images
|
