DIN X6CrAl13 Turbine Blade Steel W-Nr 1.4002

Name: DIN X6CrAl13 Turbine Blade Steel WNr 14002
Brand: PANGANGGROUP,ANSTEEL,TISCO,BAOSTEEL
Price: 3000 USD

China DIN X6CrAl13 Turbine Blade Steel W-Nr 1.4002 wholesale

Brand Name : PANGANGGROUP,ANSTEEL,TISCO,BAOSTEEL

Model Number : DIN X6CrAl13, W-Nr 1.4002

Certification : SGS,TUV,BV,ISO,MTC

Place of Origin : China

MOQ : 500kg or Negotiations

Price : 3000-5000 USD/Ton or Negotiations

Payment Terms : T/T

Supply Ability : 85000KGS/Month

Delivery Time : Ex-stock for delivery: 4-8 days Production lead time: 40-45 days

Packaging Details : Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement

Product name : DIN X6CrAl13 Turbine Blade Steel

Grades : DIN X6CrAl13, W-Nr 1.4002

Processing methods : Ground,Milled,Cold working,Machined etc.

Heat treatment condition : Quenched and tempered etc.

Surface : Rrough Turned,Grinding,Centreless Ground etc.

Profile : Forging Parts,Sheets Plates etc.

Price Term : Ex-work, FOB, CIF, CFR, DDU etc.

Contact Now

DIN X6CrAl13 Turbine Blade Steel W-Nr 1.4002

Description

All of DIN X6CrAl13 Turbine Blade Steel W-Nr 1.4002 conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.

Material:Metal,Turbine Blade Steel, DIN X6CrAl13 Turbine Blade Steel W-Nr 1.4002
Round bar / Wire rod (Diameter): 5.5mm to 800mm
Square bar / Flat bar: 3mm to 800mm
Forging piece: stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T6 - 200mm X W10 - 1500mm X L1000-12000mm

Products Details

DIN X6CrAl13 Turbine Blade Steel W-Nr 1.4002

Chemical Composition (weight%):	Mechanical Properties Under Final Heat Treatment:
C (％): ≤ 0.08 Si (％)≤: 1.00 Mn (％)≤: 1.00 P (％)≤: 0.040 S (％)≤: 0.030 Cr (％): 12.0 ~ 14.0 Al (％): 0.10 ~ 0.30	Condition: annealing Thickness/mm: - σb/MPa: 400～600 σ0.2≥/MPa: 250 δ5≥(％): 20 ψ≥(％): 60 Akv≥/J: - Hardness HBS30: ≤185

DIN X6CrAl13 Turbine Blade Steel W-Nr 1.4002

Applications:

DIN X6CrAl13 Turbine Blade Steel W-Nr 1.4002 used most often in the has many structural and defense applications. Aircraft steel D6AC Turbine Blade Steel martensitic used most often in thevehicle, airplane, pressure vessel, power generations, etc.

Technical Standard	Equivalent Grade
ISO/TS 15510(2003)	X6Cr13
JIS G4303(2005)	SUS 405
KS D3706(2006)	STS 405
IS 6527(2001)	X04Cr13
DIN EN 10088-1(2005)	X6Cr13/1.4000
NF EN 10088-2(2005)	X6Cr13
NF A35-573(1984)	Z6CA13
BS 970-1(1996)	403S17
ASTM A959(2004)	405/S40500

DIN X6CrAl13 Turbine Blade Steel W-Nr 1.4002

FAQ

Q: How do you control the quality?

A: We have professional inspectors to analyze the chemical composition of raw materials and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.

Q: Do you accept customization?

A: Yes. If you have special requirements for products or packaging, we can make them for you.

Q: Can you accept trial orders?

A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.

Q: How do I get samples?

A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.

DIN X6CrAl13 Turbine Blade Steel W-Nr 1.4002
