FV520B Stainless Steel Round Bar

Name: FV520B Stainless Steel Round Bar
Brand: PANGANGGROUP,ANSTEEL,TISCO,BAOSTEEL
Price: 1 USD

China FV520B Stainless Steel Round Bar wholesale

Brand Name : PANGANGGROUP,ANSTEEL,TISCO,BAOSTEEL

Model Number : FV520B

Certification : SGS,TUV,BV,ISO,MTC

Place of Origin : China

MOQ : Negotiations

Price : Negotiations

Payment Terms : T/T

Supply Ability : 55000KGS/Month

Delivery Time : Ex-stock for delivery: 3-7 days Production lead time: 30-60 days

Packaging Details : Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement

Product name : FV520B Stainless Steel Round Bar

Grades : FV520B

Processing methods : shot blasted, Milled, Cold working, etc.

Heat treatment condition : solution treated, quenched and tempered, etc.

Surface : Rrough Turned, Grinding, Centreless Ground, etc

Available Shapes : Round bar, Flat bar, Length, Heavy, middle plate via hot rolled, Sheet steel via cold rolled, Steel strip via cold rolled, Forging piece,etc

Price Term : Ex-work, FOB, CIF, CFR, DDU etc.

Contact Now

FV520B Stainless Steel Round Bar

Description

FV520B Stainless Steel Round Bar Primary applications are for parts and accessories that require corrosion resistance, high strength, and good ductility.
All of FV520B Stainless Steel Round Bar conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.

Material:Metal,Stainless Steel Round Bar, FV520B
Shape:Stainless Steel Round Bar
Round bar / Wire rod (Diameter): 5.5mm to 800mm
Square bar / Flat bar: 3mm to 800mm
Forging piece: stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T6 - 200mm X W10 - 1500mm X L1000-12000mm
Sheet steel via cold rolled: T0.5 - 6mm X W6 - 1000mm X L1000 - 2000mm

Products Details

FV520B Stainless Steel Round Bar

Chemical Composition (weight%):	Mechanical Properties Under Final Heat Treatment:
C (％): ≤ 0.07 Si (％): ≤ 0.70 Mn (％): ≤ 1.00 P (％)≤: 0.035 S (％)≤: 0.025 Cr (％): 13.0 ~ 15.0 Ni (％): 5.00 ~ 6.50 Mo (％): 1.20 ~ 2.00 Other (％): Cu 1.20 ~ 2.00, Nb 0.20 ~ 0.70	Form: Round bar Condition: double overaged,1050º C +2 hours 750-850 ºC,+2 hours 750-850 ºC Proof stress (N/mm²): 800 Tensile strength, σb/MPa: 925 ~ 1035 Yield strength, σ0.2/MPa: 775 Elongation, δ (％): 15.0 Hardness \| HB: 277 ~ 341 Impact strength, AKv /Min: 54

FV520B Stainless Steel Round Bar

Applications:

FV520B Stainless Steel Round Bar is often used in the pump shafts, impellers, fasteners, valves, hydraulic equipment used in oil and gas industries, marine and nuclear engineering, and aircraft components such as steam turbine blades.

FV520B Stainless Steel Round Bar

FAQ

Q: How do you control the quality?

A: We have professional inspectors to analyze the chemical composition of raw materials and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.

Q: Do you accept customization?

A: Yes. If you have special requirements for products or packaging, we can make them for you.

Q: Can you accept trial orders?

A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.

Q: How do I get samples?

A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
